导斜器The Deflector
导斜器The Deflector的简介:导斜器The Deflector
![导斜器The Deflector 导斜器The Deflector](../../images/tp/thjx_csa_001b.jpg)
导斜器也叫斜向器或造斜器。它是引导磨铣工具从一侧磨铣套铣管形成窗口的专用工具。按结构分为三种基本结构型式:DZS注水泥式导斜器、QMD 卡瓦液压锚定导斜器和 QMFD 卡瓦液压锚定封隔器式导斜器。
The deflector,also called as deviator, is a specialized tool which is used to lead milling tool to mill the one side of casing to form a window .The deflectors are available in three types:DZS type cementing deflector ,QMD type slip hydralaulic anchored deflector and QMFD type slip hydraulic packer deflector.
型号 | 外径(mm) | 长度(mm) | 钢球直径(mm) | 斜铁角度 | 接头口型 | 套管内径(mm) |
ZSD114 | 114 | 2750 | 30 | 3° | NC31 | 124.3~127.3 |
ZSD139 | 139 | 3300 | 35 | 3° | NC38 | 144.2~153.7 |
ZSD152 | 152 | 3650 | 35 | 3° | NC38 | 154.8~166.1 |
ZSD203 | 203 | 4900 | 40 | 3° | 6 5/8"REG | 216.8~228.7 |
ZSD114 | 114 | 3230 | 22 | 3° | NC31 | 124.3~127.3 |
ZSD139 | 139 | 3820 | 30 | 3° | NC38 | 144.2~153.7 |
ZSD152 | 152 | 4230 | 35 | 3° | NC38 | 154.8~166.1 |
ZSD203 | 203 | 5820 | 40 | 3° | 6 5/8"REG | 216.8~228.7 |
ZSD114 | 114 | 3700 | 22 | 3° | NC31 | 124.3~127.3 |
ZSD139 | 139 | 4290 | 30 | 3° | NC38 | 144.2~153.7 |
ZSD152 | 152 | 4700 | 35 | 3° | NC38 | 154.8~166.1 |
ZSD152 | 203 | 6410 | 40 | 3° | 6 5/8"REG | 216.8~228.7 |
